Copier Specifications |
Copying process | Electrostatic laser copy |
Toner system | Simitri ™- polymerised toner |
Copy/print speed A4 mono (cpm) | 22 |
Copy/print speed A3 mono (cpm) | 15 |
Autoduplex speed A4 mono (cpm) | 22 |
1st Copy/print time mono (sec) | 5.3 |
Warm-up time (sec) | Approx. 24 |
Copy resolution (dpi) | 600 x 600 |
Gradations | 256 |
Multi-copy | 1 - 999, interruption mode |
Original format | Up to A3 |
Magnification | 25 - 400% in 0.1% steps
auto zooming |
Copy functions | Cover and page insertion, book copy, image repeat, proof copy, job setting memory, Overlay, stamp, watermark, (with optional hard disc) |
Printer Specifications |
Print resolution (dpi) | 600 x 600 |
Controller CPU Speed | 300MHz |
Page description language | PCL 6, PostScript 3 |
Operating systems | Windows NT4.0/2000/XP/XP64/Vista/Vista64
Windows Server 2000/2003/2003 x64/Server2008
Macintosh OS 9.2 or later
Macintosh OS X 10.2,3,4/10.4 Intel or later
Unix/Linux/Citrix |
Printer fonts | 80x PCL Latin
136x PostScript 3 Emulation Latin |
Print functions | Mixmedia and mixplex, Job programming 'Easy Set”, Overlay, Watermark |
Scanner Specifications |
Scan Speed mono (opm) | up to 70 |
Scan resolution (dpi) | Max.: 600 x 600 |
Scan modes | Network TWAIN scan (optional), scan-to-email, scan-to-FTP, scan-to-SMB, scan-to-Box (optional) |
File formats | PDF, TIFF |
Scan destinations | 540, LDAP support |
Fax Specifications |
Fax standard | Super G3 (optional) |
Fax transmission | Analogue, i-Fax, IP-Fax |
Fax resolution (dpi) | Max.: 600 x 600 |
Fax compression | MH, MR, MMR, JBIG |
Fax modem (Kbps) | 33.6 |
Fax destinations | 540 |
Fax functions | Polling, Memory Transmission, Receipt to email/SMB/Box |
User box specification |
Box functionality | Optional |
Max. user boxes | 1,000 |
Type of user boxes | Public, personal (with password or authentication), secure print |
User box functionality | Reprint, download, sending |
System Specifications |
System memory standard (MB) | 192 |
System memory optional (MB) | 320 |
System hard disc optional (GB) | 40 |
Interfaces standard | 10-Base-T/100-Base-TX Ethernet, USB 2.0 |
Interfaces optional | Parallel IEEE1284 |
Network protocols | TCP/IP, IPX/SPX, AppleTalk (EtherTalk), SMB, LPD, IPP, SNMP, HTTP |
Automatic document feeder | Optional
Up to 80 originals
A5 - A3
35 - 128g/m² |
Paper size | A6 - A3 full bleed |
Printable paper weight (g/m²) | 50 - 210 |
Paper input capacity (sheets) | Standard: 1,150
Max.: 3,650 |
Paper trays standard | Tray 1: 500 sheets
A5 - A3
60 - 90g/m²
Tray 2: 500 sheets
A5 - A3
60 - 90g/m²
Manual Bypass: 150 sheets
A6 - A3
50 - 210g/m²
|
Paper trays optional | Tray 3: 500 sheets
A5 - A3
60 - 90g/m²
Tray 3 + 4: 2x 500 sheets
A5 - A3
60 - 90g/m²
Large Capacity Cabinet: 2,500 sheets
A4
60 - 90g/m²
|
Automatic duplexing | A5 - A3
60 - 90g/m² |
Finishing modes (optional) | Offset, group, sort, staple, punch, centre-fold, booklet, mail-bin sort |
Output capacity (w. finisher) | Max. 1,200 sheets |
Output capacity (w/o finisher) | Max. 200 sheets |
Stapling | 50 sheets |
Booklet | 15 sheets |
Copy/print volume recommended (monthly) | 4,500 |
Copy/print volume max. (monthly) | 19,000 |
Toner lifetime Black | 17,500 |
Imaging Unit lifetime Black | 65,000 (Drum/Developer) |
Power consumption | 220-240 V / 50/60Hz
Less than 1.47 KW (system) |
System dimensions (WxDxH, mm) | 677 x 710 x 718 |
System weight (kg) | Approx. 74 |
System Features |
Security | ISO 15408 EAL3 (in evaluation), IP filtering, SSL network communication, user authentication, secure print, hard disc overwrite, hard disc data encryption (optional) |
Accounting1 | Up to 100 user accounts, LDAP support |
Software | PageScope Net Care Device Manager
PageScope Data Administrator
PageScope Box Operator
PageScope Workware (Trial)
Print Status Notifier |
