| Copying process | Electrostatic laser copy |
| Toner system | Simitri - polymerised toner |
| Copy/print speed A4 mono (cpm) | Up to 55 ppm |
| Copy/print speed A3 mono (cpm) | Up to 27 ppm |
| Autoduplex speed A4 mono (cpm) | Up to 55 ppm |
| 1st Copy/print time mono (sec) | 4.1 |
| Warm-up time (sec) | Approx. 22¹
¹ Warm-up time may vary depending on the operating environment and usage |
| Copy resolution (dpi) | 600 x 600 |
| Gradations | 256 gradations |
| Multi-copy | 1 - 9,999 |
| Original format | A5 - A3 |
| Magnification | 25-400% in 0.1% steps, auto-zooming |
| Copy functions | Chapter, cover and page insertion, proof copy (print and screen), adjustment test print, digital art functions, job setting memory, poster mode, image repeat, overlay (optional), stamping, copy protection |
| Print resolution (dpi) | 1,800 x 600 dpi, 1,200 x 1,200 dpi |
| Page description language | PCL6 (XL 3.0), PCL 5, PostScript 3 (CPSI 3016), XPS |
| Operating systems | Windows VISTA (32/64)
Windows 7 (32/64)
Windows 8 (32/64)
Windows 10 (32/64)
Windows Server 2008 (32/64)
Windows Server 2008 R2 (64)
Windows Server 2012 (64)
Windows Server 2012 R2
Macintosh OS X 10.x
Unix, Linux, Citrix |
| Printer fonts | 80 PCL Latin, 137 PostScript 3 Emulation Latin |
| Print functions | Direct print of PCL, PS, TIFF, XPS, PDF, encrypted PDF files and OOXML (DOCX, XLSX, PPTX), mixmedia and mixplex, ″Easy Set” job programming, overlay, watermark, copy protection, carbon copy print |
| Scan Speed mono (opm) | Up to 160 ipm |
| Scan resolution (dpi) | Max.: 600 x 600 |
| Scan modes | Scan-to-eMail (Scan-to-Me)
Scan-to-SMB (Scan-to-Home)
Scan-to-FTP
Scan-to-Box
Scan-to-USB
Scan-to-WebDAV
Scan-to-DPWS
Network TWAIN scan |
| File formats | JPEG, TIFF, PDF, PDF/A 1a and 1b (optional), Compact PDF, encrypted PDF, searchable PDF (optional), XPS, compact XPS, PPTX, searchable PPTX (optional), searchable DOCX/XLSX (optional) |
| Scan destinations | 2,100 (single + group), LDAP support |
| Scan functions | Annotation (text/time/date) for PDF, up to 400 job programs, Realtime scan preview |
| System memory standard (MB) | 2,048 |
| System hard disc standard (GB) | 250 |
| Interfaces standard | 10-Base-T/100-Base-T/1,000-Base-T Ethernet, USB 2.0, Wi-Fi 802.11b/g/n (optional) |
| Network protocols | TCP/IP (IPv4 / IPv6), IPX/SPX, NetBEUI, AppleTalk (EtherTalk), SMB, LPD, IPP, SNMP, HTTP |
| Frame types | Ethernet 802.2, Ethernet 802.3, Ethernet II, Ethernet SNAP |
| Automatic document feeder | Up to 100 originals, A6-A3, 35-163 gsm
Dualscan ADF |
| Paper size | A6-SRA3, customised paper sizes,
banner paper max. 1,200 x 297 mm |
| Printable paper weight (g/m² ) | 52-300 |
| Paper input capacity (sheets) | Standard: 1,150
Max.: 6,650 |
| Paper trays standard | Tray 1: 500 sheets, A5-A3, 52-256 gsm
Tray 2: 500 sheets, A5-SRA3, 52-256 gsm
Manual Bypass: 150 sheets, A6-SRA3, custom sizes, banner, 60-300 gsm |
| Paper trays optional | Tray 3: 500 sheets, A5-A3, 52-256 gsm
Tray 3 + 4: 2 x 500 sheets, A5-A3, 52-256 gsm
Large Capacity Cabinet: 2,500 sheets, A4, 52-256 gsm
Large Capacity Cabinet (1): 3,000 sheets, A4, 52-256 gsm
Large Capacity Cabinet (2): 2,500 sheets, A4-SRA3, 52-256 gsm |
| Automatic duplexing | A5-SRA3, 52-256 gsm |
| Finishing modes (optional) | Offset, group, sort, staple, punch, post insertion, centre-fold, letter fold, booklet |
| Output capacity (w. finisher) | Max.: 3,300 sheets |
| Output capacity (w/o finisher) | Max.: 250 sheets |
| Stapling | Max.: 100 sheets or 94 sheets + 2 cover sheets (up to 209 gsm) |
| Stapling output capacity | Max.: 1,000 sheets |
| Letter fold | Up to 3 sheets |
| Letter fold capacity | Max.: 30 sheets (tray), unlimited |
| Booklet | Max.: 20 sheets (90gsm) or 19 sheets (90gsm) + 1 cover sheet (up to 209 gsm) |
| Booklet output capacity | Max.: 100 sheets (tray), unlimited |
| Copy/print volume recommended (monthly) | 30,000 |
| Copy/print volume max. (monthly) | 150,000 |
| Toner lifetime Black | 29,280 |
| Imaging Unit lifetime Black | 135,000 pages/600,000 pages (Drum/Developer) |
| Power consumption | 220-240 V / 50/60 Hz, Less than 2.0 kW (system) |
| System dimensions (WxDxH, in.) | 24.21 x 26.97 x 36.26 |
| System weight (lb.) | 205.03 lb. |
| Security | ISO 15408 EAL3 (in evaluation), IEEE 2600.1 compliat, IP filtering and port blocking,
SSL2, SSL3 and TSL1.0 network communication,
IPsec support, IEEE 802.1x support, user authentication,
Authentication log, secure print,
Hard disk overwrite (8 standard types),
Hard disk data encryption (AES 128),
Memory data auto deletion, Confidential fax receipt,
Print user data encryption, copy protection
(Copy Guard, Password Copy) optional |
| Accounting | Up to 1,000 user accounts, Active Directory support (user name + password + e-mail + smb folder)
User function access definition
Biometric authentication (finger vein scanner) optional
ID card authentication (ID card reader) optional |
| Software | PageScope Net Care Device Manager
PageScope Data Administrator
PageScope Box Operator
PageScope Direct Print
Print Status Notifier
Driver Packaging Utility
Log Management Utility |
